Industrial AI Visual Suite Industrial AI detection vision suite, is a covering software and algorithm system, AI computing system, optical imaging system, structural electrical system, graphic industrial control system as one of the overall industrial vision solution.This scheme is mainly aimed at high-end manufacturing and production terminals, and solves such problems as high labor cost, low detection efficiency, single detection type, difficult expansion of defect type, and less covering defect form。 Features ntegrate the optical imaging scheme, control and detection scheme of the products in industrial testing, making it more convenient to cooperate with each other, intuitive to view the data, and more efficient to shorten the debugging period。 Application This solution has flexible application, clear process, convenient assembly, extensive application scenarios, etc. It can be directly installed to the original production line without additional extension and major change of production line. It has low requirements for workshop environment, and it has ultra-high cost performance ratio, which greatly reduces the cost of AI testing for enterprises。 |
Hardware:
-
camera -
light -
Controller
Software:
-
Transport control system
-
Galileo-X
Deep industrial visual recognition system -
Galileo-T
Online detection system -
Galileo-T
Big data system
-
Medicine packing box -
Tablets -
Capsule -
Medicine plate -
Reaction cup -
Jelly -
Pastry -
Bread -
Jelly suction bag -
Plastic food packaging -
Metal coil -
Copper clad -
Screw, nut -
Gear,Bearing,Silicon seal -
RCL -
Quadrate lithium battery -
Soft roll lithium battery -
Cylindrical lithium battery -
Electrode -
Separators
Medicine plate detection
Surface detection
Speed：≥500pcs/min
Result：Loss ≤ 0.001% | Fault ≤ 0.001%
Type：Deformation、foreign body、line error、blow-by......
-
master map
-
result
Medicine boxes
Surface detection
Speed：≥500pcs/min
Result：Loss ≤ 0.001% | Fault ≤ 0.001%
Type：Damaged,smudged,medicine box opening,deformation,label curling......
-
master map
-
result
OCR test of medicine plate and box
Surface detection
Speed：≥500pcs/min
Result：Precision rate ≥ 99.99%
-
master map
-
result
The finished jelly
Surface detection
Speed：≥100pcs/min
Result：Loss ≤ 0.2% | Fault ≤ 5%
Type：Hair, pulp insects, black residue, air bubbles, iron filings......
-
master map
-
result
Face detection
Surface detection
Speed：≥235pcs/min
Result：Loss ≤ 1% | Fault ≤ 1%
Type：Singe, foreign body, hair, dirty......
-
master map
-
result
Steel plate detection
Surface detection
Speed：≥120pcs/min
Result：Loss ≤ 0.1% | Fault ≤ 5%
Type：Burr, scratch, bruise......
-
master map
-
result
